Early litho pathfinding, process optimization and analysis

S-Litho represents advanced lithography simulation for semiconductor device manufacturing process development and optimization. It covers a wide range of applications in proximity printing, optical, immersion, extreme ultraviolet (EUV), and electron beam (e-beam) lithography. Process-limiting effects within the imaging system of an exposure tool can be thoroughly analyzed, taking the impact of mask and substrate topography on photoresist patterning into account. Interfacing S-Litho with Synopsys TCAD tools allows a seamless modeling of complex integration techniques such as double-patterning. The link between S-Litho and Synopsys Proteus mask synthesis applications accelerates the generation and validation of optical proximity correction (OPC) models and improves process robustness.

Key Benefits

cost-saving.svg

Modeling Reference

Eliminating costly experiments.

parallel.svg

Technology Coverage

From proximity printing to high-NA EUV Litho.

Topmost Performance

High predictivity and efficient DP scaling.

Features

S-Litho

S-Litho provides a comprehensive set of features to predict the outcome of a photolithographic process. Physics-based models enable high simulation accuracy.  As a computational lithography tool, S-Litho accelerates process development and reduces cost by eliminating experiments.

Key features include:

  • Wide range of lithographic techniques: Proximity printing, e-beam direct write, DUV projection lithography
  • Resist modeling in three dimensions (3D)
  • Resist model calibration environment
  • Powerful customization through scripting
  • Links to Synopsys’ Proteus and TCAD solutions

S-Litho EUV

S-Litho EUV enables process optimization and development for the most advanced nodes. It’s ready for all high-NA EUV specific simulation applications, allowing to start the development of mask synthesis solutions today, while the exposure tool hardware is still under development.

Key features include:

  • Isomorphic and anamorphic imaging
  • High speed mask 3D simulations,
  • Multi-layer defect assessment
  • Metal-Oxide resist and dry resist processing
  • Stochastic models and defectivity studies
